Detalii produs:
- Papuc inelar neizolat
- Material : aluminiu |
Product Description
ACYY / ACYY-F – Low voltage power cable 0.6/1 kV
1. Cable construction
Conductor: aluminum (class 1 or 2), monowire (re), multiwire (rm).
Insulation: PVC
Filling.
Outer sheath: PVC, black or grey.
Application
Power supply to power stations. The cables can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Technical data and tests
| Conductor type : |
monowire (re), multiwire (rm) |
| Rated voltage Uo/U : |
0.6/1 kV |
| Test voltage : |
4 kV AC or 12 kV DC, 5 min |
| Min. temperature of cable : |
installation : -5º C |
| Max. allowed operating temperature : |
70º C |
| Max. short-circuit temperature : |
160º C |
| Min. bending radius : |
15 x cable diameter – single-core cable
12 x cable diameter – multicore cable |
| Max. tensile strain during installation : |
max 50 N/mm² |
| Color coding : |
1 conductor-blue or yellow-green;
2 conductors – blue,brown;
– yellow-green,black for sect > 10 mm²;
3 conductors – brown,black,grey;
– yellow-green, blue,brown;
4 conductors – blue, brown, black,grey;
– yellow-green, brown,black,grey;
5 conductors – blue, brown, black, grey, black;
– yellow-green, blue, brown, black,grey;
More than 5 conductors: – numbered black conductors;
– yellow-green and numbered conductors. |
| Standards:
Cable : IEC 60502-1.
Conductors : IEC 60228.
Insulation : IEC 60502-1.
Flame retardancy:
ACYY : EN 50265-2-1 (IEC 60332-1) – flames on a single vertical cable.
ACYY-F : EN 50266-2-4 (IEC 60332-3-25 Cat. C) – flames on a bundle of cables. |
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Applications
ACYY / ACYY-F is a cable for power supply to power stations. This cable can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Other standards
British : AL/PVC/PVC.
German : NAYY.
Austrian : E-AYY.
Russian : АВВГ.
Central Europe : PP 00-A.
Turkish : YAVV-R.
|
Tubul capat, tip e2508, are o sectiune intre 0.5-50mm si este realizat din cupru stanat, iar izolatia este din plastic termorezistent de diferite culori. Acesta este destinat a fi montat ca terminal cablurilor multifilare la clema.
Unitatea de ambalare este set de 100 bucati.
Specificatii tehnice
| Garantie Persoana Fizica (luni) |
24 |
| Garantie Persoana Juridica (luni) |
24 |
| Model |
UGN10-4-D25-04-08 |
| Material |
cupru stanat |
|
|
| Tip izolatie |
plastic termorezistent |
| Sectiune (mmp) |
0.5-50 |
| Temperatura de lucru (grade C) |
( - 40 .. +80 ) grade Celsius |
| Cantitate |
100 buc |
|
Product Description
ACYY / ACYY-F – Low voltage power cable 0.6/1 kV
1. Cable construction
Conductor: aluminum (class 1 or 2), monowire (re), multiwire (rm).
Insulation: PVC
Filling.
Outer sheath: PVC, black or grey.
Application
Power supply to power stations. The cables can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Technical data and tests
| Conductor type : |
monowire (re), multiwire (rm) |
| Rated voltage Uo/U : |
0.6/1 kV |
| Test voltage : |
4 kV AC or 12 kV DC, 5 min |
| Min. temperature of cable : |
installation : -5º C |
| Max. allowed operating temperature : |
70º C |
| Max. short-circuit temperature : |
160º C |
| Min. bending radius : |
15 x cable diameter – single-core cable
12 x cable diameter – multicore cable |
| Max. tensile strain during installation : |
max 50 N/mm² |
| Color coding : |
1 conductor-blue or yellow-green;
2 conductors – blue,brown;
– yellow-green,black for sect > 10 mm²;
3 conductors – brown,black,grey;
– yellow-green, blue,brown;
4 conductors – blue, brown, black,grey;
– yellow-green, brown,black,grey;
5 conductors – blue, brown, black, grey, black;
– yellow-green, blue, brown, black,grey;
More than 5 conductors: – numbered black conductors;
– yellow-green and numbered conductors. |
| Standards:
Cable : IEC 60502-1.
Conductors : IEC 60228.
Insulation : IEC 60502-1.
Flame retardancy:
ACYY : EN 50265-2-1 (IEC 60332-1) – flames on a single vertical cable.
ACYY-F : EN 50266-2-4 (IEC 60332-3-25 Cat. C) – flames on a bundle of cables. |
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Applications
ACYY / ACYY-F is a cable for power supply to power stations. This cable can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Other standards
British : AL/PVC/PVC.
German : NAYY.
Austrian : E-AYY.
Russian : АВВГ.
Central Europe : PP 00-A.
Turkish : YAVV-R.
|
Product Description
ACYY / ACYY-F – Low voltage power cable 0.6/1 kV
1. Cable construction
Conductor: aluminum (class 1 or 2), monowire (re), multiwire (rm).
Insulation: PVC
Filling.
Outer sheath: PVC, black or grey.
Application
Power supply to power stations. The cables can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Technical data and tests
| Conductor type : |
monowire (re), multiwire (rm) |
| Rated voltage Uo/U : |
0.6/1 kV |
| Test voltage : |
4 kV AC or 12 kV DC, 5 min |
| Min. temperature of cable : |
installation : -5º C |
| Max. allowed operating temperature : |
70º C |
| Max. short-circuit temperature : |
160º C |
| Min. bending radius : |
15 x cable diameter – single-core cable
12 x cable diameter – multicore cable |
| Max. tensile strain during installation : |
max 50 N/mm² |
| Color coding : |
1 conductor-blue or yellow-green;
2 conductors – blue,brown;
– yellow-green,black for sect > 10 mm²;
3 conductors – brown,black,grey;
– yellow-green, blue,brown;
4 conductors – blue, brown, black,grey;
– yellow-green, brown,black,grey;
5 conductors – blue, brown, black, grey, black;
– yellow-green, blue, brown, black,grey;
More than 5 conductors: – numbered black conductors;
– yellow-green and numbered conductors. |
| Standards:
Cable : IEC 60502-1.
Conductors : IEC 60228.
Insulation : IEC 60502-1.
Flame retardancy:
ACYY : EN 50265-2-1 (IEC 60332-1) – flames on a single vertical cable.
ACYY-F : EN 50266-2-4 (IEC 60332-3-25 Cat. C) – flames on a bundle of cables. |
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Applications
ACYY / ACYY-F is a cable for power supply to power stations. This cable can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV – Other standards
British : AL/PVC/PVC.
German : NAYY.
Austrian : E-AYY.
Russian : АВВГ.
Central Europe : PP 00-A.
Turkish : YAVV-R.
|
Product Description
ACYY / ACYY-F - Low voltage power cable 0.6/1 kV
1. Cable construction
Conductor: aluminum (class 1 or 2), monowire (re), multiwire (rm).
Insulation: PVC
Filling.
Outer sheath: PVC, black or grey.
Application
Power supply to power stations. The cables can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV - Technical data and tests
| Conductor type : |
monowire (re), multiwire (rm) |
| Rated voltage Uo/U : |
0.6/1 kV |
| Test voltage : |
4 kV AC or 12 kV DC, 5 min |
| Min. temperature of cable : |
installation : -5º C |
| Max. allowed operating temperature : |
70º C |
| Max. short-circuit temperature : |
160º C |
| Min. bending radius : |
15 x cable diameter - single-core cable
12 x cable diameter - multicore cable |
| Max. tensile strain during installation : |
max 50 N/mm² |
| Color coding : |
1 conductor-blue or yellow-green;
2 conductors - blue,brown;
- yellow-green,black for sect > 10 mm²;
3 conductors - brown,black,grey;
- yellow-green, blue,brown;
4 conductors - blue, brown, black,grey;
- yellow-green, brown,black,grey;
5 conductors - blue, brown, black, grey, black;
- yellow-green, blue, brown, black,grey;
More than 5 conductors: - numbered black conductors;
- yellow-green and numbered conductors. |
| Standards:
Cable : IEC 60502-1.
Conductors : IEC 60228.
Insulation : IEC 60502-1.
Flame retardancy:
ACYY : EN 50265-2-1 (IEC 60332-1) - flames on a single vertical cable.
ACYY-F : EN 50266-2-4 (IEC 60332-3-25 Cat. C) - flames on a bundle of cables. |
ACYY / ACYY-F low voltage power cable 0.6./1 kV - Applications
ACYY / ACYY-F is a cable for power supply to power stations. This cable can be installed in open or confined areas, underground (in pipes), in sewers, in concrete, in places where no mechanical damage is expected.
ACYY / ACYY-F low voltage power cable 0.6./1 kV - Other standards
British : AL/PVC/PVC.
German : NAYY.
Austrian : E-AYY.
Russian : АВВГ.
Central Europe : PP 00-A.
Turkish : YAVV-R.
|
