Description

Supply of polyethylene double layer corrugated pipes, produced for continuous co-extrusion of both layers
extruded by UNI EN ISO 9001:2015 and system of environmental management conforming to the norm UNI
EN ISO 14001:2015.
Pipes are of red colour externally and black colour internally, supplied in of 25 or 50 meter coils,
comprehensive with jointing coupler and a galvanized wire to pull the cables.
They must correspond to CEI EN 61386-1/-24 standard and have IMQ mark and CE marking with product
classification series N and have stiffness resistance higher than 450 N.
– GENERAL CHARACTERISTICS –
CONSTRUCTION: Double layer pipe, external corrugated of red colour and smooth internally of black
colour.
APPLICATION: Electrical cable protection (low and medium tension) and telephone cables.
STIFFNESS RESISTANCE: CEI EN 61386-1/-24 with deformation level of internal diameter equal to 5%
IMQ – CE marking.
STRUCTURE: stable to UV rays with one-year guarantee for date of production shown on the pipe.
BENDING RADIUS: 15 times the external diameter.
LIMITS OF APPLICATION: -50 °C / +60 °C
LENGTHS: in 50 meter coils (ø 200mm coils of 25 meters)
ACCESSORIES: Jointing coupler + pulling wire
INSTALLATION: Underground in trench.

Brand

CORRUGATI
